Corrosion Resistance of Novel Coatings on Ferritic Steels for Oxycombustion–Supercritical Steam Boilers: Preliminary Results
(Springer Nature Link, 2015-07-23) Agüero, Alina; Baraibar, Ignacio; González, Vanessa; Muelas Gamo, Raúl; Plana, Daniel; European Commission; Ministerio de Economía y Competitividad (MINECO)
Increasing the efficiency of coal fired steam power plants is an important contribution towards clean coal power. In fact, new ferritic steels are expected to withstand 325 bar and 650 °C. Moreover, in order to facilitate CO2 capture oxygen can be used instead of air for combustion (oxycombustion) so that no NOX emissions are produced. Boiler components, such as superheater tubes, are exposed to both steam and fireside corrosion and at higher temperatures, ferritic steels corrode at very fast rates under both atmospheres. A solution can be found in the use of protective coatings, a number of which, applied by techniques capable of depositing said coatings both on the inner and outer surfaces of tubes, are being studied within nationally and European funded projects. In particular, two new Ni and Cr modified aluminide coatings deposited on P92 by non-line-of-sight hybrid processes have been produced and the preliminary results of on-going laboratory testing, both under oxycombustion model atmospheres as well as under pure steam at 650 °C are promising, in particular those exhibited by the Cr enriched aluminide coating. Moreover, results obtained in a pilot oxycombustion boiler operated by CIUDEN in Leon, Spain are also shown.
Performance of HIPIMS deposited CrN/NbN nanostructured coatings exposed to 650 °C in pure steam environment
(Elsevier, 2016-05-20) Hovsepian, P.; Ehiasarian, A. P.; Purandare, Y. P.; Biswas, B.; Pérez, F. J.; Lasanta, M. I.; De Miguel, M. T.; Illana, A.; Juez Lorenzo, M.; Muelas Gamo, Raúl; Agüero, Alina
In the current work, 4 μm thick CrN/NbN coating utilising nanoscale multilayer structure with bi-layer thickness of Δ = 2.9 nm has been used to protect 9 wt% Cr steels such as P92 widely used in steam power plants. The uniquely layered coatings have a combination of nitrides of chromium and niobium which are not only resistant to aqueous corrosion and corrosion-erosion and have excellent tribological properties, but also have oxidation resistance in dry air up to a temperature of 850 °C. The novel High Power Impulse Magnetron Sputtering (HIPIMS) deposition technology has been used to deposit CrN/NbN with enhanced adhesion (critical load of scratch adhesion LC2 = 80 N) and a very dense microstructure as demonstrated by Transmission Electron Microscopy (TEM) imaging. These superior coating properties are achieved due to the unique high metal ion content (up to 90%) in the HIPIMS plasma, which allows particle acceleration and trajectory control by external electrical and magnetic fields thus delivering highly energetic material flux on the condensing surface.
P92 bare and coated samples were oxidised at 650 °C in 100% steam atmosphere up to 2000 h, in order to simulate the future operation conditions of steam turbines employed in power plants. The oxidation kinetics was evaluated by mass gain measurements. Under these conditions CrN/NbN provided reliable protection of the P92 steel. The paper also discusses the effect of growth defects and high temperature crack formation analysed by Scanning Electron Microscopy and Focused Ion Beam-Scanning Electron Microscopy techniques (SEM and FIB-SEM, respectively) on the high temperature corrosion resistance in pure steam atmosphere thus revealing the coatings potential failure mechanisms.
