Validation procedure of low level coupling tests on real aircraft structure
(IEEE Xplore, 2012-12-31) Fernández Romero, Sergio; López Morales, Andrés; Añón Cancela, M.; Gutierrez, Guadalupe G.; European Commission (EC)
This paper describes the analysis of the experimental test results obtained during the low level swept coupling (LLSC) and low level direct drive (LLDD) tests on FALCON 7X horizontal tail plane provided by EADS-CASA. These techniques are evaluated during the aircraft high intensity radiated field (HIRF) certification process and in the scope of European Community's FP7 HIRF SE project. The analysis of low level test results shall be performed to estimate the influence of the test setup with particular regard to the in-flight coupling configuration. For this reason, finite difference time domain (FDTD) 3D computations have been used to determine the relationship between free field external radiation and skin current in different illumination angles and polarizations. Finally, after validation by comparison of the measured and computed skin current, measured bundle current are related to measured skin currents, to provide the transfer function link to the external field.
On the Use of FDTD for HIRF Validation and Certification
(The Electromagnetic Academy (USA), 2012-06-12) Gutierrez, Guadalupe G.; Fernández Romero, Sergio; Álvarez, Jesús ; González García, Salvador; Pascual Gil, Enrique; Ministerio de Ciencia e Innovación (MICINN); European Commission (EC); Junta de Andalucía
Preparing the 3D-geometry models to perform electromagnetic compatibility (EMC) numerical simulations can be tedious and time consuming. Furthermore, the need to include the test setup in the models, in order to validate the software, by comparing the numerical results with the measured data, may lead to unwieldy simulation models with often una ordable computational costs. In this paper, we provide strategies for optimizing and simplifying the modeling process, together with guidelines for achieving the most unfavorable case in the simulation of EMC problems, as required for a certi cation process. A test case from the European FP7 HIRF-SE project is analyzed in this paper as an example of how to identify the unnecessary elements for the simulation, while retaining the essential physics of the problem.
